Our group has been wandering around Stonehouse in order to pick a location.

We identified several potential sites with a large enough area of white space which ain’t heavily lit at night.

The final decision as to where we position it will be based on what we wish to achieve and if it will be practical.

A bluetooth device is non directional and has no sense of space or direction, it only knows when another device is in range and has started talking to it; so on its own a single device is very limited. A couple of my posts including this address several of the ways useful for visualising the actual space using this data.

Another solution using multiple adapters to extrapolate multiple dimensions is to have multiple devices at a single location. As mentioned in a previous post there are three classes of bluetooth device each with a different theoretical range. The class of adapter can indicate the distance of the detected device. However there will be large variations, for a device to be detected two-way communication must be briefly established, if one device is a Class 3 with only a couple of metres range it will not be able to communicate with a Class 1 device that is 50 meters away because the maximum range between two devices is that of the lowest. However higher class devices also tend to be more sensitive and are able to detect weaker classes’ signals out of those devices normal range so I would expect to see a slightly improved range for them. This will mean that detecting class 3 devices may not be possible with a class 1 device on the other side of the road.

With three bluetooth adapters each indicating various distances it can be possible to locate a device within this space. If the device appears on all three adapters the device must be passing closely to the scanner. If it appears on the class 1 adapter only then it can be determined to be beyond the range or penetration of the other scanners. One problem is that cars provide shielding preventing bluetooth contact, possibly only allowing the most powerful adapter to detect it. When this is combined with the use of multiple locations to determine speed and therefore the method of locomotion these can be correctly identified as cars due to the unique ID and displayed correctly. Further testing is required to identify if this is viable.

One possibility we have explored is that because of the way we have observed Union street to be used as a conduit rather than a destination with the vast majority of people passing through the space without interacting within it. The idea is to use two of these devices positioned at either end of Union Street or multiple devices along it. This would allow us to add another dimension to our projected visualisation. For example speed can be calculated by collating devices that have matching unique ID’s to form a narrative. At one location a person’s device is detected, the time is recorded and the person continues down the street where their device is detected by another scanner and the time is logged. The time difference can be calculated and if the distance is known then an approximate speed can be given.

From the speed we can also try to predict how the device is being carried. 1.5m/s would suggest walking speed whereas something faster would possibly indicate the use of a car.

As I we are using Bluetooth for our project it seems prudent to say a little bit about it.

Bluetooth is a wireless protocol for exchanging data over short distances from fixed and mobile devices.

Going into the technical details, “Bluetooth uses a radio technology called frequency-hopping spread spectrum, which chops up the data being sent and transmits chunks of it on up to 79 frequencies. In its basic mode, the modulation is Gaussian frequency-shift keying (GFSK). It can achieve a gross data rate of 1 Mb/s. Bluetooth provides a way to connect and exchange information between devices such as mobile phones, telephones, laptops, personal computers, printers, Global Positioning System (GPS) receivers, digital cameras, and video game consoles through a secure, globally unlicensed Industrial, Scientific and Medical (ISM) 2.4 GHz short-range radio frequency bandwidth. The Bluetooth specifications are developed and licensed by the Bluetooth Special Interest Group (SIG). The Bluetooth SIG consists of companies in the areas of telecommunication, computing, networking, and consumer electronics.”

Infact everything you will ever want to know (most likely not alot) about Bluetooth can be found here.

A key thing of interest for me from this are the different power classes which would have a significant effect on how good at detecting phones we can be.

“In most cases the effective range of class 2 devices is extended if they connect to a class 1 transceiver, compared to a pure class 2 network. This is accomplished by the higher sensitivity and transmission power of Class 1 devices.”

So using a Class 1 adapter would be better even if most mobile devices only use a class 2 or 3.

EDIT: After looking into it, it should be very easy to get one of these class 1 bluetooth adapters with 100m range and cover an entire street, including cars passing through.

http://www.nirsoft.net/utils/bluetooth_viewer.html

Bluetooth enabled phones are constantly transmitting an ID which can be set by their user. A simple scan with a phone can reveal these names which people are outputting often without realising.

I have come up with the idea of using a laptop with a bluetooth adapter to record the names which people have assigned to their phones as they walk by. Similar to wardriving but staying still and with the people move around the receiver. The information that can be gathered from this is the ability to see the movement of these devices and therefore the people carrying them. This data could then be visually represented on a website in real time and projected onto the side of a building.

I suspect there may not be enough pedestrians during winter passing through to do it how I would like and the busiest part of Stonehouse, Union Street, isn’t really busy enough to show the information in real time as I would prefer so we would have to present it in a way that displays it for a while. A problem would be to get the data to output in a usable format and setting up the stream and possilby combining the information with another feed of some kind.

Maybe it would be an interesting thing to do in the city centre…
